TP-Link Omada S7500-48Y8C 25G L3 Core Switch
TP-Link Omada S7500-48Y8C 25G L3 Core Switch
The TP-Link Omada Campus S7500-48Y8C is an enterprise 48-port 25G stackable L3 Managed Aggregation/Core Switch featuring 48× 25Gbps SFP28 slots and 8× 100Gbps QSFP28 slots. Built for high-performance campus core and aggregation networks, it supports physical stacking, M-LAG, OSPF, BGP, IS-IS, VRF, VRRP, ECMP, PBR, ERPS, BFD, NETCONF, PTPv2, advanced security, and centralized Omada cloud management, with two field-replaceable power supplies for enhanced availability.
S7500-48Y8C
Omada Campus 48-Port 25G Stackable L3 Managed Aggregation/Core Switch with 8× 100G Slots — Enterprise-grade technical specifications
Hardware Features
Interface
48× 1/10/25G SFP28 Slots
8× 40/100G QSFP28 Slots
2× USB 3.0 Ports
1× RJ45 Console Port
1× USB Type-C Console Port
1× RJ45 Management Port
8× 40/100G QSFP28 Slots
2× USB 3.0 Ports
1× RJ45 Console Port
1× USB Type-C Console Port
1× RJ45 Management Port
Fan Quantity
Five Field-replaceable and Hot-swappable Fans
Power Supply
Two Field-replaceable and Hot-swappable Power Supply Modules (100–240 VAC, 50/60 Hz)
*Shipping with one PSM550-AC module by default, and another field-replaceable redundant power supply requires purchasing separately.
*Shipping with one PSM550-AC module by default, and another field-replaceable redundant power supply requires purchasing separately.
Dimensions (W x D x H)
17.3 × 16.5 × 1.7 in (440 × 420 × 44 mm)
Mounting
Rackmountable
Max. Power Consumption
• 225.3 W max @ 220V/50Hz 25 °C
• 231.2 W max @ 110V/60Hz 25 °C
• 231.2 W max @ 110V/60Hz 25 °C
Max. Heat Dissipation
• 768.27 BTU/hr @ 220V/50Hz 25 °C
• 788.6 BTU/hr @ 110V/60Hz 25 °C
• 788.6 BTU/hr @ 110V/60Hz 25 °C
Performance
Switching Capacity
4 Tbps
Stacking
• Stacking Number: 12 in standalone mode, 4 in controller mode
• Stacking Port: 100G QSFP28 slots (All 8 slots can be used as stacking ports)
• Stacking Bandwidth: 1.6 Tbps
• Stacking Port: 100G QSFP28 slots (All 8 slots can be used as stacking ports)
• Stacking Bandwidth: 1.6 Tbps
Packet Forwarding Rate
2.8 Bpps
MAC Address Table
Max 256 K
Packet Buffer Memory
24 MB
Jumbo Frame
9 KB
Software Features
M-LAG
• M-LAG domain configuration
• DAD (Dual-Active Detection)
• Peer-link-port LAG
• DAD (Dual-Active Detection)
• Peer-link-port LAG
PTP
• IEEE 1588v2 (PTPv2), IEEE 802.1AS
• Clock-type: oc, bc, e2etc, p2ptc
• Clock-type: oc, bc, e2etc, p2ptc
Quality of Service
• Class of Service: 8 Queues, Port Priority, IEEE 802.1p, DSCP/ToS
• Priority Schedule Mode: SP/WRR per Queue
• Bandwidth Control: Rate Limit, Storm Control
• Voice VLAN · WRED
• Priority Schedule Mode: SP/WRR per Queue
• Bandwidth Control: Rate Limit, Storm Control
• Voice VLAN · WRED
L3 Features
• L3 Interface: 4,094 (IPv4, IPv6)
• Static Route: 2,048 IPv4, 1,024 IPv6
• IPv4 Network Router Entries: Max 516,096
• IPv6 Network Router Entries: Max 258,048
• ECMP · Dynamic ARP: 45,056 · ND: 45,056
• DHCPv4 Server · DHCP Relay
• VRRPv2/v3 · OSPFv2/v3 · RIPv1/v2 · RIPng
• VRF · IS-ISv4/v6 · BGPv4
• PIM-SM/PIM-DM/PIM-SSM
• IGMPv1/v2/v3 · BFD · PBR · uRPF
• Static Route: 2,048 IPv4, 1,024 IPv6
• IPv4 Network Router Entries: Max 516,096
• IPv6 Network Router Entries: Max 258,048
• ECMP · Dynamic ARP: 45,056 · ND: 45,056
• DHCPv4 Server · DHCP Relay
• VRRPv2/v3 · OSPFv2/v3 · RIPv1/v2 · RIPng
• VRF · IS-ISv4/v6 · BGPv4
• PIM-SM/PIM-DM/PIM-SSM
• IGMPv1/v2/v3 · BFD · PBR · uRPF
L2 and L2+ Features
• LACP / Static LAG · STP / RSTP / MSTP
• ERPS · Port Isolation · Loopback Detection
• Port Security · Sticky MAC · 802.3x Flow Control
• Port Mirror · RSPAN · LLDP · LLDP-MED
• Multicast: IGMP Snooping, MLD Snooping, MVR, Fast Leave, IGMP Querier
• ERPS · Port Isolation · Loopback Detection
• Port Security · Sticky MAC · 802.3x Flow Control
• Port Mirror · RSPAN · LLDP · LLDP-MED
• Multicast: IGMP Snooping, MLD Snooping, MVR, Fast Leave, IGMP Querier
Advanced Features
• Automatic Device Discovery · Batch Configuration
• Batch Firmware Upgrading · Intelligent Network Monitoring
• Abnormal Event Warnings · Unified Configuration · Reboot Schedule
‡Requires Omada Pro SDN Controller
• Batch Firmware Upgrading · Intelligent Network Monitoring
• Abnormal Event Warnings · Unified Configuration · Reboot Schedule
‡Requires Omada Pro SDN Controller
ISP Features
• 802.3ah Ethernet Link OAM · L2PT
• Device Link Detect Protocol (DLDP) · DDM · sFlow
• Device Link Detect Protocol (DLDP) · DDM · sFlow
VLAN & Security
VLAN
• 802.1Q VLAN: 4K VLANs · MAC VLAN: 200 entries
• Protocol VLAN (IEEE 802.1v): 16 Templates, 12 Groups
• QinQ: 256 entries · Private VLAN · GVRP
• Protocol VLAN (IEEE 802.1v): 16 Templates, 12 Groups
• QinQ: 256 entries · Private VLAN · GVRP
Security
• IP-MAC-Port Binding: 1,024 Entries · ARP Scanning
• IPv6-MAC-Port Binding: 1,024 Entries
• ARP Inspection · ND Detection
• IP Source Guard · IPv6 Source Guard
• RA Guard: 30 entries · DoS Defend
• DHCP Filter · 802.1X (RADIUS, TACACS+)
• ACL · Secure boot
• IPv6-MAC-Port Binding: 1,024 Entries
• ARP Inspection · ND Detection
• IP Source Guard · IPv6 Source Guard
• RA Guard: 30 entries · DoS Defend
• DHCP Filter · 802.1X (RADIUS, TACACS+)
• ACL · Secure boot
Management & Others
Omada App
Yes, through Omada Pro Controller
Centralized Management
Omada Pro Cloud/ Hardware / Software Controller
Zero-Touch Provisioning
Yes (requires Omada Pro Cloud-Based Controller)
Management Features
• Web-based GUI · CLI (console, telnet)
• SNMPv1/v2c/v3 · RMON (1,2,3,9)
• SDM Template · DHCP/BOOTP Client
• LLDP/LLDP-MED · DHCP Auto Install
• Dual Image, Dual Configuration · CPU Monitoring
• Password Recovery · SNTP · System Log
• SNMPv1/v2c/v3 · RMON (1,2,3,9)
• SDM Template · DHCP/BOOTP Client
• LLDP/LLDP-MED · DHCP Auto Install
• Dual Image, Dual Configuration · CPU Monitoring
• Password Recovery · SNTP · System Log
Package Content
S7500-48Y8C Switch · Power Cord · RJ45 Console Cable
Locking Strap · Rackmount Kit · Rubber Feet · Quick Installation Guide
Locking Strap · Rackmount Kit · Rubber Feet · Quick Installation Guide
System Requirements
Windows® 98SE, NT, 2000, XP, Vista™, 7/8/10/11 · MAC® OS · NetWare® · UNIX® · Linux
Environment
• Operating Temp: -5℃ to 45℃ (23℉ to 113℉) @ 300m
-5℃ to 40℃ @ 2,000m · -5℃ to 35℃ @ 3,000m
• Storage Temp: -40℃ to 70℃ (-40℉ to 158℉)
• Operating Humidity: 10%–90% RH non-condensing
• Storage Humidity: 5%–90% RH non-condensing
-5℃ to 40℃ @ 2,000m · -5℃ to 35℃ @ 3,000m
• Storage Temp: -40℃ to 70℃ (-40℉ to 158℉)
• Operating Humidity: 10%–90% RH non-condensing
• Storage Humidity: 5%–90% RH non-condensing
